Technical Data
Related Items
- Type: Pack
- Model:
- Cell Size Compatible:
- Chemistry: Li-ion
- Nominal Capacity (mAh): 2200
- Nominal Voltage (V): 11.1
- Charge Cut-off Voltage:
- Discharge Cut-off Voltage:
- Maximum Charge Current:
- Maximum Discharge Current: 2 C
- Charge Current:
- Standard: 0.2C
- Rapid: 0.5C
- Typical Capacity (mAh):
- Minimum Capacity: 2090mAh
- Number of Cells:
- Indicators:
- Charging Indicator:
- Charging Current:
- AA/C/D:
- AAA:
- 9V:
- USB Output:
- Maximum Current:
- Charging Time:
- End Voltage of Discharge: 8.25V
- Typical Discharge:
- Maximum Discharge:
- Standard Discharge: 0.2C
- Compatible Chemistry:
- Over Charge Protection:
- Over Charge Detection Voltage: 4.35±0.025V
- Over Charge Release Voltage: 4.15±0.05V
- Rated Current:
- Over Discharge Protection:
- Over Discharge Detection Voltage: 2.4±0.08V
- Over Discharge Release Voltage: 3.0±0.1V
- Rated Discharge Current: 5A
- Over Current Detection Current: 5.7-7.7A
- Input Voltage:
- Input Current:
- Charging Voltage Range:
- Rated Charging Current:
- Trickle Charging Current:
- LED Indicators:
- No Battery:
- Charging:
- Fully Charged:
- Short Circuit:
- Reverse Polarity:
- Non-Rechargeable:
- Bulb:
- Output Levels:
- High Mode:
- Low Mode:
- Strobe:
- Battery:
- Cycle Life: >300cycles
- Approx. Length:
- Approx. Width:
- Approx. Depth:
- Approx. Weight:
- Trickle Mode:
- Timer:
- AAA/AA:
- C:
- D:
- 9V:
- –?V auto cut-off for:
- Temperature Range:
- Charge: 0~45℃
- Discharge: -20~60℃
- Storage:
- Less Than 30 Days:
- Less Than 90 Days: 0 ~ 35℃
- Less Than 1 Year: -20 ~ 25℃
- Within 1 Month:
- Within 6 Months:
- Safety Features:
- Casing Dimension:
- Humidity:
- Weight: Approx:145g
- Operating Temperature:
- Operating Humidity: 60±25%R.H
- Storage Temperature:
- Storage Humidity: 60±25%R.H
- Protection Circuit Module:
- Short Circuit Protection:
- Short Protection:
- Release Condition:
- Interior Resistance:
- P+, P- Conductive Resistance:
- Current Consumption:
- Average Current Consumed:
- Dimensions: 70 x 56 x 19mm (L x W x T)
- Included Accessories:
|
|
|
|
